Theory of Dielectric Analysis and Cure Monitoring

Terms and Definitions: Here are some common terms and definitions used in the study of dielectric analysis.

Basics of Thermoset Cure and Dielectric Measurements: Thermosets are an important class of materials used for adhesives, coatings and composites. They include epoxies, (poly)urethanes, acrylics, phenolics, vinyl esters, silicones and many other compounds. Uncured thermosets, or A-stage materials, are composed of small molecules called monomers

Linear vs. Logarithmic Scales: During cure, the conductance GMUT of a thermoset between the electrodes of a sensor changes by several orders of magnitude. Before processing starts, conductance is normally low because the material is either in a solid state or is at a temperature too low for significant crosslinking. Typically the thermoset is cured by heating to an elevated temperature. As the material becomes warm and softens, the conductance increases. The rate of crosslinking increases with temperature, also, and at some point its influence dominates and the material begins to harden—conductance reaches a maximum at this time then decreases as the material becomes more viscous then rigid. By the end of cure the conductance may have decreased by a factor of 100 or more from its peak value. Plotting conductance on a logarithmic scale is the optimum method for seeing all the information available from dielectric measurements.

Dielectric Measurements-Viscosity and Critical Points: Dielectric cure monitoring measures the bulk conductance and capacitance of Material Under Test (MUT), which are used to calculate the material properties of conductivity and permittivity.

Ion Viscosity and Loss Factor: Calculating loss factor and ion viscosity.

Ion Viscosity and Temperature: For the measurement of mechanical viscosity and cure state, ion viscosity (DC resistivity) provides valuable information from a simple electrical measurement. Ion viscosity depends on the mobility of free ions under the influence of an electric field, but also varies with temperature. Therefore, correct interpretation of ion viscosity requires knowledge of temperature at the time of measurement and an understanding of how temperature influences the data. For brevity, ion viscosity will alternatively be called IV.

Sensor A/D Ratio and Base Capacitance: Measurements of dielectric properties often involve the use of simple parallel plate electrodes. However, their separation can change with pressure, or expansion and contraction of the material between them. The ratio of electrode area A and the distance D between them—the A/D ratio—therefore may not be well known. As the scaling factor between conductance and conductivity, or capacitance and permittivity, uncertainty in A/D causes inaccuracies in determining dielectric material properties.

Measuring Degree of Cure with DEA: Data from dielectric cure monitoring (DEA) correlate with glass transition temperatures (Tg) obtained from differential scanning calorimetry (DSC). In many cases a linear relationship exists between log (ion viscosity) and Tg. Dielectric measurements can be converted to Cure Index, which is a reproducible indicator of the state of cure. For some materials, Cure Index closely follows the degree of cure calculated by the DiBenedetto equation, which uses glass transition temperature information.

Dielectric Measurement Techniques: Dielectric instrumentation measures the conductance G (or resistance R) and capacitance C between a pair of electrodes at a given frequency. The Material Under Test (MUT) between a pair of electrodes can be modeled as a conductance in parallel with a capacitance.

Parallel Plate Measurements: Dielectric instrumentation measures the electrical properties of the Material Under Test (MUT) between a pair of electrodes, which can be modeled as a conductance in parallel with a capacitance.

Calculating A/D Ratio and Base Capacitance: The cross section of the planar electrodes shown in Figure 15-1 shows that the total capacitance Ctot is the sum of CMUT from the Material Under Test above electrodes and Cbase from the substrate beneath the electrodes. This second component Cbase is called the base capacitance.

Electrode Polarization and Boundary Layer Effects: When the incorrect model is used to determine dielectric properties, low frequency measurements of highly conductive materials may appear to have unusually low conductivity. This phenomenon is caused by electrode polarization, the accumulation of charge against the electrodes, which occurs when the material under test ....

Electrochemical Modeling of AC and DC Cure Monitoring: Both AC and DC measurements can probe the cure state of thermosets and composites, so it is important to understand their characteristics when deciding which to use. During early through mid-cure, electrochemical reactions can affect DC results, while these effects are not evident in AC measurements. Consequently, DC measurements have limitations in accuracy for some portion of the cure, but at properly chosen frequencies AC results are accurate through the entire cure. Although the nature of the resin electrochemistry is unknown, a DC electrochemical resistance added to the model of a curing thermoset can reproduce the behavior of DC resistance measurements.

Electrical Modeling of Polymers: The dielectric—literally “two-electric”—properties of conductivity s, and permittivity e, arise from ionic current and dipole rotation in bulk material. For polymers, mobile ions are often due to impurities and additives, while dipoles result from the separation of charge on nonpolar bonds or across a molecule. When analyzing dielectric properties, it is possible and convenient to separate the influence of ions from dipoles to consider their individual effects.
